At a glance
Active Quasi 3-way full range with DSP · 15"×2+2"+ Horn · 4Ω · 128dB
| Type | Active Quasi 3-way full range with DSP |
|---|---|
| Component | 15"×2+2"+ Horn |
| Nominal Impedance | 4Ω |
| RMS Power Handling | LF:600W;HF:80W |
| Peak Power Handling | LF:1200W;HF:160W |
| Amp output (HF) | 100W/8Ω, RMS |
| Amp output (LF) | 600W/8Ω, RMS |
| DSP | 2 in 4 out 24 bit DSP |
| Frequency Response | 45Hz-20KHz |
| Sensitivity(1W/1M) | 103dB |
| Max SPL | 128dB |
| Dispersions | 110ºH ×55º V |
| Horn throat size | 1"(25mm) |
| Voice coil size | 2"(44mm) |
| Crossover | 1.65KHz |
| Dimension HWD(mm) | 1095×465×455 |
| Shipping HWD(mm) | 1160×520×510(0.31CBM) |
| NW/GW(Kg) | 54.5/59.1 |
| PSA25 | ||
|---|---|---|
| Type / Component / Nominal Impedance / RMS Power Handling / Peak Power Handling / Amp output (HF) / Amp output (LF) / DSP / Frequency Response / Sensitivity(1W/1M) / Max SPL / Dispersions / Horn throat size / Voice coil size / Crossover / Dimension HWD(mm) / Shipping HWD(mm) / NW/GW(Kg) | Active Quasi 3-way full range with DSP / 15"×2+2"+ Horn / 4Ω / LF:600W;HF:80W / LF:1200W;HF:160W / 100W/8Ω, RMS / 600W/8Ω, RMS / 2 in 4 out 24 bit DSP / 45Hz-20KHz / 103dB / 128dB / 110ºH ×55º V / 1"(25mm) / 2"(44mm) / 1.65KHz / 1095×465×455 / 1160×520×510(0.31CBM) / 54.5/59.1 |
Need PSA25 quoted?
Send quantities and your venue details — we reply with pricing, lead time and a coverage prediction.
