Description
TASSO latest LARK series is a high-end compact line array system designed for high-definition voice and music transmission in challenging venues. Especially in the natural reverberation of large places long distance application, with high-definition voice and music reproduction of the outstanding acoustic performance.
| Model | LARK 808A | D212BA |
|---|---|---|
| Speaker Components | 8 x 3'' Nd / 8 x 1'' Nd SOFT DOME TWEET-ER | Dual 12'' WOOFER |
| Description | Combined Hybird Line Source Array Speaker System | RE-FLEX bandpass Low frequency speaker system |
| Power AES / Peak | LF:240 W / 960 W ; HF: 80 W / 320 W | 400W + 400W / 1600W + 1600W |
| Impedance nominal | LF:4Ω / HF:4Ω | 8Ω + 8Ω |
| SPL / 1W / Peak @ 1 m | LF: > 99 dB / 129 dB / HF: > 99 dB / 124 dB | 100dB / 135 dB |
| Useble Range | 90 Hz - 20 kHz ( -6 dB ) | 35 Hz -200Hz |
| Tuning Frequency excursion mini-mum | 120 Hz | 40 Hz - 160 Hz |
| X - Over point acoustical | Depends on preset | Depends on preset |
| Coverage horizontal / Vertical | 120° x 20° | N / L |
| Mechanical Splay Angle | 0° -8° | 0° |
| Electronic part | Built - in 2* 600W power amplifier and DSP | Built - in 4*600w power amplifier and DSP; / Bridge mode drives per woofer. |
| Connectors | 1 XLR input, 1 XLR link-out, 1 PowerCON, 1 PowerLOOP,1 USB, 2 RJ45 RS485 | 1 XLR input , 1 XLR link-out, 1 PowerCON, 1 Powe-LOOP, 1 USB, 2 RJ45 RS485 |
| Coding: | Non | Non |
| Weight ( KG ) | 9.3 | 45 |
| Size ( height x width x depth ) ( mm ) | 375*270*285 | 700*460*600 |
