Description
Lark Compact is a small and good cost performance package in the Lark System, consisting of LARK 806 and LARK 112BA.
Lark Compact is suitable for mobile use, LARK 112BA low-frequency speakers with a unique storage design, storage and transportation can be combined with the LARK 806 into a whole, a great savings in transport and storage space.
| LF | 240 W / 960 W ; HF: 60 W / 240 W |
|---|---|
| HF | > 97 dB / 121 dB |
| X - Over point acoustical | Depends on preset |
| Coverage horizontal / Vertical | 120° x 20° |
| Mechanical Splay Angle | 0° -8° |
| Electronic part | Non, Powered by active woofer |
| Connectors | 2 x Speakon NL4MP in / out |
| Coding | 1 +/- LF, 2 +/- HF |
| Model | LARK 806 | LARK112BA |
|---|---|---|
| Speaker Components | 8 x 3'' Nd / 8 x 1'' Nd SOFT DOME TWEETER | 12'' WOOFER |
| Description | Integrated Hybird Line Source Array Speaker System | RE-FLEX Low frequency speaker system |
| Power AES / Peak | LF:240 W / 960 W ; HF: 60 W / 240 W | 400W + 400W / 1600W + 1600W |
| Impedance nominal | LF:8Ω / HF:8Ω | 8Ω |
| SPL / 1W / Peak @ 1 m | LF: > 99 dB / 129 dB / HF: > 97 dB / 121 dB | 97dB / 129 dB |
| Useble Range | 90 Hz - 20 kHz ( -6 dB ) | 35 Hz -200Hz |
| Tuning Frequency excursion mini-mum | 120 Hz | Built-in 4*600W power amplifier and DSP |
| X - Over point acoustical | Depends on preset | |
| Coverage horizontal / Vertical | 120° x 20° | |
| Mechanical Splay Angle | 0° -8° | |
| Electronic part | Non, Powered by active woofer | |
| Connectors | 2 x Speakon NL4MP in / out | |
| Coding: | 1 +/- LF, 2 +/- HF | |
| Net Weight ( KG ) | 9 | 32 |
| Size ( height x width x depth ) ( mm ) | 340*300*230 | 930*420*450 |
