At a glance
full range · 3" Full x2 · 4ohm · 105dB
| Type | full range |
|---|---|
| Component | 3" Full x2 |
| Nominal Impedance | 4ohm |
| RMS Power Handling | 70W |
| Peak Power Handling | 140W |
| Frequency Response | 82Hz-20KHz |
| Sensitivity(1W/1M) | 90dB |
| Max. SPL | 105dB |
| Dispersions | 160Hx17V |
| Dimension HWD(mm) | 228x105x106 |
| Shipping HWD(mm) | 228x166x165 |
| NW/GW (Kg) | 1.8/2.8 |
| TM320 | ||
|---|---|---|
| Type / Component / Nominal Impedance / RMS Power Handling / Peak Power Handling / Frequency Response / Sensitivity(1W/1M) / Max. SPL / Dispersions / Dimension HWD(mm) / Shipping HWD(mm) / NW/GW (Kg) | full range / 3" Full x2 / 4ohm / 70W / 140W / 82Hz-20KHz / 90dB / 105dB / 160Hx17V / 228x105x106 / 228x166x165 / 1.8/2.8 |
